Model:

Flame-Retardant Yellow Fiberglass Board


The flame-retardant yellow fiberglass board is a reliable insulating material designed for use in the electric power industry and mechanical equipment applications. It offers stable electrical insulation, mechanical strength, and flame resistance, making it suitable for a range of industrial environments. The board can be processed into various sizes and shapes to meet specific project requirements, providing flexibility for custom applications.

High-Quality Material: Manufactured from selected raw materials, the board provides good wear resistance and a long service life while maintaining stable performance under normal working conditions.
Non-Standard Customization: The surface is smooth, free from burrs and black spots, allowing for easy installation and precise fitting. Custom machining and processing are available to suit specific project needs.
Factory Direct Supply: Direct production reduces intermediary costs and offers competitive pricing with flexible processing options. Bulk orders can be fulfilled efficiently with consistent quality.
Durable and Processable: Maintains mechanical integrity and insulation properties, while being easy to cut, shape, and assemble for industrial applications.

Inquiry Now
  • Name Epoxy Board
    Color Yellow
    Dimension 1220×2470MM
    Thickness 0.3-200MM (commonly between 0.3-50MM)
    Features This product is made from electrical-grade fiberglass cloth and alkali-free cloth impregnated with epoxy resin,
     then processed via baking and hot pressing. The laminate has high mechanical and dielectric properties, good heat resistance and moisture resistance, as well as excellent machinability. Its heat resistance class is Class B (155°C). It is suitable for use as insulating structural components in motors and electrical appliances, and can be applied in humid environments and transformer oil. The bending strength is ≥200KG at room temperature and 100KG at high temperature; the breakdown voltage is no less than 100KV under normal conditions and no less than 20KV after dampening.
-->
